Absima USB NiMH Charger 2A 10W

Product detailed description

Simple charger for NiMH batteries (5–8 cells) with automatic charge termination when fully charged. Powered via USB adapter (e.g. phone charger, etc.).

The charger features LED indication. After connecting to the adapter, the red LED lights up. During charging, the green LED flashes while the red LED stays on. When the battery is fully charged, both green and red LEDs remain on. If only the red LED stays on after connecting the battery, an error has occurred or a protection function has been activated.

To use the full power of the charger, a sufficiently powerful USB adapter with at least 10W (2A/5V) is required, but not more than 2.4A! When using a less powerful adapter, charging will proceed at a lower current and take longer. Using a more powerful adapter (over 2.4A) may damage the charger!

Technical data:

Power supply: USB-A power adapter
Max. output power: 2A/5V
Battery type: NiMH 5–8 cells / 6V–9.6V
Battery capacity: 2000mAh – 5100mAh
Charging indication: red/green status LEDs
Protection modes: overvoltage – short circuit – reverse polarity
Connector: Tamiya
Dimensions (L/W/H): 70×25×15 mm
Weight: 22 g
